RCS Valiant 27 Inch Horizontal Single Access Door w/ Soft-Close - VDH1SC
RCS Valiant 27 Inch Horizontal Single Access Door w/ Soft-Close - VDH1SC
Is This the Right Product for Your Outdoor Kitchen?
- Choose this when your bay is wider than it is tall — the 27" wide × 20" tall horizontal door swings outward from the top or bottom hinge depending on your orientation preference.
- Ideal under sinks, grills, and side burners — per the RCS catalog, horizontal doors are specifically designed for appliance maintenance access in tight vertical clearances.
- Cutout required: 24 1/2" wide × 17 1/2" tall.
- Choose hinge side at installation — left or right swing cannot be changed after mounting without removing the door from the frame.
Key Features
- Soft-Close Hinges — spring-loaded deceleration mechanism prevents door slam. In outdoor environments, wind can catch an open door and force it shut hard enough to damage the hinge over time. Soft-close eliminates this.
- Dual Magnetic Latch — two-point magnetic closure keeps the door sealed against wind pressure, humidity, and pests. No key required; opens with a firm pull on the recessed handle.
- Full 90° Door Swing — opens completely flat against the island face for unobstructed access to the full bay interior. No partial-open clearance restrictions.
- Recessed Handle Design — handle sits flush with the door face so it doesn't protrude past the island surface line. Maintains a clean profile across a multi-component outdoor kitchen layout.
- Double-Lined 304 Stainless Steel Construction — two layers of 304 stainless on the door face add structural rigidity, preventing warping and flexing from heat cycles that can misalign the door with the frame over time.
- Reversible Hinge — choose left or right swing at installation based on your island layout and access clearance. Set permanently at installation.
Documentation
Warranty
Lifetime limited warranty to the original owner against manufacturing defects in materials and workmanship. Does not cover surface corrosion, discoloration, or damage from salt spray, improper maintenance, or chemicals.
Specs & Dimensions
RCS 27" Valiant Horizontal Access Door |
|
|---|---|
| Model | VDH1SC |
| Mounting Type | Flush |
| Orientation | Horizontal |
| Material | 304 Stainless Steel |
| Overall Width | 27" |
| Overall Depth | 1" |
| Overall Height | 20" |
| Weight | 5 Lbs |
| Cut Out Width | 24 1/2" |
| Cut Out Height | 17 1/2" |
| Number of Doors | 1 |
| Handle Type | Recessed Handle |
| Hinge Type | Left or Right Hinge Option |
| Soft-Close Door Hinge | Included |
| Magnetic Door Latches | Included |
| Warranty | Lifetime |
| Trash Bin Included | No |
| Paper Towel Holder Included | No |
| Propane Tank Included | No |
| Made in the US | Yes |
